Applications
- In machining, it is used to adsorb ferromagnetic workpieces, providing auxiliary support for processing operations.
- In the metallurgical industry, it is applied to handle and transfer ferromagnetic materials, streamlining material handling processes.
- In the mining industry, it is utilized to adsorb and remove iron impurities from ores, improving the purity of raw ore.
Core Features
Safe and Reliable Performance: By eliminating the need for mechanical clamping, it fundamentally reduces the risk of workpiece falling off during use, ensuring stable and secure operation.
Strong Magnetic Adsorption Capacity: It delivers high magnetic force—when energized, it generates a powerful magnetic field, enabling reliable adsorption of heavy ferromagnetic objects.
Easy and Efficient Operation: The adsorption and release of workpieces/members are controlled by electric current, allowing quick and precise operation without complex manual adjustment.
Type/Parameter
UOM
BTEC70
BTEC80
BTEC120
BTEC130
BTEC150
Weight
kg
490
620
1800
2010
2830
Overall Dimension(DIA)
mm
700
800
1200
1300
1500
Power
Kw
3.3
3.96
9.02
12
15.6
Max current (cold-state)
A
15
18
41
54
71.2
Work Load( Large steel ingot)
kg
2500
3000
7500
8500
11000
Work Load( Cast iron ingot)
kg
380/200
480/250
1200
1400/1100
1900/1500
Work Load( Iron scrap)
kg
120/100
150/130
600
700/600
1100/900
Construction and Engineering Projects:
- Foundation excavation: Excavating foundations and basements for residential buildings, commercial high-rises, or industrial plants.
- Road and bridge construction: Used for subgrade leveling, excavation, and backfilling, as well as bridge foundation construction.
- Tunnel excavation: Used for clearing earth and rock in tunneling projects.
Infrastructure and Utility Projects:
- Pipeline laying: Digging and backfilling trenches for water, electricity, gas, and telecommunication lines.
- Water conservancy projects: Used for building dams, canals, flood embankments, and dredging rivers.
Mining and Quarrying Projects:
- Open-pit mining: Used for stripping topsoil and excavating minerals.
- Material loading and unloading: Loading excavated materials onto transport trucks.
Demolition and Environmental Projects:
- Building demolition: Used with hydraulic shears or hammers to demolish old buildings.
- Waste clearing: Removing construction waste and handling industrial waste.
- Site remediation: Used for excavating and restoring contaminated land.
Agricultural and Landscaping Projects:
- Farmland transformation: Leveling land and digging irrigation channels.
- Landscaping: Used in large-scale projects for digging, moving trees, and grading terrain.
Contact Qingdao Britop for more information if you are interested.
