Product Uses
- Efficiently handles house demolition tasks: separates steel bars from concrete, bends bars, and loads materials onto trucks—greatly boosting work efficiency.
- Works 2–3 times faster than a breaking hammer. Fully mechanized operation ensures safety and saves time.
- Low noise and no vibration, meeting environmental standards. Suitable for urban and industrial park demolition projects.
Product Features
- Large jaw opening, minimal occlusion gaps, fast jaw movement, and dual anti-leakage design—enables quick crushing of reinforced concrete blocks.
- Equipped with a steel bar cutting blade, which cuts exposed bars during operation to enhance crushing efficiency.
- Upper and lower jaws are made of high-hardness wear-resistant steel, ensuring strong wear resistance, longer service life, and higher economic benefits.
- Added oil circuit acceleration valve speeds up jaw engagement, further improving work efficiency.
Contact Qingdao Britop for more information if you are interested.
Parameter |
UOM |
BTWG03 |
BTWG04 |
BTWG06 |
BTWG08 |
BTWG10 |
Suitable Excavator |
ton |
3.5-5 |
6-10 |
12-18 |
20-28 |
30 |
Weight |
kg |
280 |
400 |
900 |
1500 |
1700 |
Opening |
mm |
1500 |
1500 |
1900 |
2000 |
2000 |
Height |
mm |
125 |
140 |
190 |
220 |
230 |
Working Pressure |
bar |
110-140 |
120-160 |
150-170 |
160-180 |
160-180 |
Set Up Pressure |
bar |
170 |
180 |
190 |
200 |
210 |
Working Flow |
lpm |
30-55 |
50-100 |
90-110 |
100-140 |
130-170 |
